En pocas palabras
¿Para quién es?
Para quien busca ampliar rutas y desnivel con asistencia, valorando autonomía y control.
Compra acompañada
Revisión previa, ajuste básico, explicación de entrega y contacto directo con el taller.
Ficha técnica
| Cuadro | Carbon HMF Main Frame, Alloy SST-CST, Integrated Suspension Technology, Virtual 4 Link kinematic, Adjustable head angle, Syncros Cable Integration System, TQ HPR60, UDH Interface, 12x148mm with 55mm Chainline |
|---|---|
| Horquilla | Marzocchi Z2 Air Rail, Sweep Adj, 15x110mm QR axle, tapered steerer, 44mm offset, Reb. Adj., Lockout, 150mm travel |
| Transmisión | SRAM Eagle 70 Transmission 12 Speed |
| Motor | TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh, US: 20mph |
| Batería | TQ Internal 360Wh + TQ Range Extender 160Wh |
| Frenos | SRAM DB4 Stealth 4-Piston Disc |
| Ruedas | Maxxis Assegai, 2.5", 60TPI Foldable, Tubeless Ready, EXO+ 3C Maxx Terra |
Ficha completa del fabricante
| Cuadro | Carbon HMF Main Frame, Alloy SST-CST, Integrated Suspension Technology, Virtual 4 Link kinematic, Adjustable head angle, Syncros Cable Integration System, TQ HPR60, UDH Interface, 12x148mm with 55mm Chainline |
|---|---|
| Viaje | Front: 150mm, Rear: 155mm |
| Horquilla | Marzocchi Z2 Air Rail, Sweep Adj, 15x110mm QR axle, tapered steerer, 44mm offset, Reb. Adj., Lockout, 150mm travel |
| Amortiguador trasero | X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 155-100-Lockout, T185X55mm |
| Sistema remoto | SCOTT TracLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes |
| Motor eléctrico | TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh, US: 20mph |
| Batería | TQ Internal 360Wh + TQ Range Extender 160Wh |
| Pantalla | TQ HPR, Bluetooth, ANT+, Dedicated Smartphone app |
| Cargador | TQ 100-240V-4A |
| Desviador trasero | SRAM Eagle 70 Transmission 12 Speed |
| Palancas de cambio | SRAM Eagle 70 Shifter |
| Bielas | Praxis Alloy |
| Guiacadenas | e*thirteen, e*spec Slider |
| Plato | Praxis alloy spider, SRAM Eagle Transmission 34T chainring |
| Cadena | SRAM CN Eagle 70 Transmission |
| Cassette | SRAM Eagle XS 1270 Transmission 10-52 |
| Frenos | SRAM DB4 Stealth 4-Piston Disc |
| Disco de freno | SRAM HS2 Rotors F&R 200mm |
| Manillar | Syncros Hixon 2.0 Alloy 6061, Size S & M 15mm rise, Size L & XL 25mm rise, back sweep 8°, 780mm, Syncros Endurance lock-on grips |
| Potencia | Syncros AM 2.0, Syncros Cable Integration System, 4° rise, 6061 Alloy, 31.8mm, 1 1/8" |
| Tija de sillín | Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mm, S size 140mm, M size 180mm, L size 180mm, XL size 210mm |
| Sillín | Syncros Tofino 2.0 Regular |
| Juego de dirección | Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Buje delantero | Formula CL-811, 15x110mm |
| Buje trasero | Formula CL-148S, 12x148mm |
| Radios | Stainless Black 15G, 1.8mm |
| Llantas bicicleta | Syncros X-30S, 32H, 30mm, Sleeve Joint, Tubeless ready |
| Neumático delantero | Maxxis Assegai, 2.5", 60TPI Foldable, Tubeless Ready, EXO+ 3C Maxx Terra |
| Neumático trasero | Maxxis Dissector, 2.5", 60TPI Foldable, Tubeless Ready, EXO+ 3C Maxx Terra |
| Peso en kg (aprox.) | 19.8 Tubless setup without RE (1.1kg) |
| Peso en Lbs (aprox.) | 43.65 Tubless setup without RE (1.1kg) |
| Peso total (máximo) | 130kg, El peso total incluye la bicicleta, el piloto, el equipo y el posible equipaje adicional. |
