En pocas palabras
¿Para quién es?
Para quien busca ampliar rutas y desnivel con asistencia, valorando autonomía y control.
Compra acompañada
Revisión previa, ajuste básico, explicación de entrega y contacto directo con el taller.
Ficha técnica
| Cuadro | Carbon HMF, Integrated Suspension Technology, Virtual 4 Link kinematic, Adjustable head angle, Syncros Cable Integration System, TQ HPR60, UDH Interface, 12x148mm with 55mm Chainline |
|---|---|
| Horquilla | FOX 36 Factory Air GripX2, HSC - LSC - HSR - LSR adjustable, 15x110mm QR axle, tapered steerer, 44mm offset, 160mm travel |
| Transmisión | SRAM GX Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System |
| Motor | TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh, US: 20mph |
| Batería | TQ Internal 360Wh + TQ Range Extender 160Wh |
| Frenos | SRAM Maven Silver Stealth 4-Piston Disc |
| Ruedas | Syncros Revelstoke 1.0-30 CL, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready Carbon rim 28H, DT Swiss Ratchet Hubs, XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools |
Ficha completa del fabricante
| Cuadro | Carbon HMF, Integrated Suspension Technology, Virtual 4 Link kinematic, Adjustable head angle, Syncros Cable Integration System, TQ HPR60, UDH Interface, 12x148mm with 55mm Chainline |
|---|---|
| Viaje | Front: 160mm, Rear: 155mm |
| Horquilla | FOX 36 Factory Air GripX2, HSC - LSC - HSR - LSR adjustable, 15x110mm QR axle, tapered steerer, 44mm offset, 160mm travel |
| Amortiguador trasero | FOX FLOAT X NUDE Factory EVOL Piggy Back Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Climb-Ramp Control-Descend, Custom large Air volume, Comp & Reb. Adj. Travel 155-100-Climb, T185X55mm |
| Sistema remoto | TracLoc Technology, Rear Suspension & Dropper Remote, 3 Rear Suspension modes |
| Motor eléctrico | TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh, US: 20mph |
| Batería | TQ Internal 360Wh + TQ Range Extender 160Wh |
| Pantalla | TQ HPR Color, Bluetooth, ANT+, Dedicated Smartphone app |
| Cargador | TQ 100-240V-4A |
| Desviador trasero | SRAM GX Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System |
| Palancas de cambio | SRAM AXS Rocker Pod Controller |
| Bielas | SRAM GX Eagle, Alloy |
| Guiacadenas | e*thirteen, e*spec Slider |
| Plato | SRAM XX Eagle Transmission 34T chainring |
| Cadena | SRAM CN GX Eagle Transmission |
| Cassette | SRAM GX Eagle XS 1275 Transmission 10-52 |
| Frenos | SRAM Maven Silver Stealth 4-Piston Disc |
| Disco de freno | SRAM HS2 Rotors F&R 200mm |
| Manillar | Syncros Hixon iC Carbon, Size S & M 15mm rise, Size L & XL 25mm rise, back sweep 8°, 780mm, Syncros Endurance lock-on grips |
| Tija de sillín | Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mm, S size 140mm, M size 180mm, L size 180mm, XL size 210mm |
| Sillín | Syncros Tofino 1.5 Regular, Titanium rails |
| Juego de dirección | Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Juego de ruedas | Syncros Revelstoke 1.0-30 CL, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready Carbon rim 28H, DT Swiss Ratchet Hubs, XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools |
| Neumático delantero | Maxxis Assegai, 2.5", 60TPI Foldable, Tubeless Ready, EXO+ 3C Maxx Terra |
| Neumático trasero | Maxxis Dissector, 2.5", 60TPI Foldable, Tubeless Ready, EXO+ 3C Maxx Terra |
| Extras | SRAM AXS Extension Cord |
| Peso en kg (aprox.) | 19.1 Tubless setup without RE (1.1kg) |
| Peso en Lbs (aprox.) | 42.11 Tubless setup without RE (1.1kg) |
| Peso total (máximo) | 130kg, El peso total incluye la bicicleta, el piloto, el equipo y el posible equipaje adicional. |
